The 4062K EC Front Steer U-Build-It Kit provides many components to build your own front steer front axle for racing lawnmowers and other small engine vehicles.
All you should need is a front beam, tie rods, and drag links with the accompanying hardware to build axles to your desired specs. If you are running USLMRA or ARMA, we recommend using one of our front axles built to the spec of those class rules.
Front Steer Spindles are most commonly built for a prepared class race mower that uses a stock chassis with more ground clearance than the FX or Outlaw classes. The front steer means the tie rod that connects the two spindles is in front of the axle beam, and the left side spindle has a drag link arm that connects to the pitman’s arm on the steering shaft via a drag link tie rod.
These spindles do not come ready for front brakes. You’ll need to notch the spindle axes for a brake key to set them up for front brakes. The axles are standard 5/8″ and will use 5/8″ front hubs.
Kit Items:
4x 728 1/2″ Heim Joint (Not Drilled)
4x 50FNFJ0Z 1/2″-20 Jam Nut
6x 50FNsJ0 1/2″-20 Slotted Jam Nut
2X FCRP-4053 Aluminum Caster End Plates
2x Steel Caster Back Plates
2x 50F45HCS5Z 1/2″-20 x 4-1/2 Hex Bolt (Not Drilled)
12X 4065 1/2″ x .154
1X 4062 EC Front Steer Spindles
14X 2511 5/8″ Spindle Spacers Radius
2X 62FNSJ0 5/8″-18 Slotted Jam Nut
8X 999-31 Large Cotter Reuseable Pins
